Gigabyte H262-P60
High Density Arm Server – Ampere® Altra® Max – 2U 4-Node 24-Bay SATA
Characteristics:
- 2U-4 nodes rear access server system
- Hardware-level root of trust support
- Ampere® Altra® Max or Altra® Processors
- Dual processor, 7nm technology
- 8-Channel RDIMM/LRDIMM DDR4 per processor, 64 x DIMMs
- Dual ROM Architecture
- 8 x 1Gb/s LAN ports (Intel® I350-AM2)
- 4 x Dedicated management ports
- 1 x CMC port
- 24 x 2.5″ SATA hot-swappable bays
- 4 x M.2 slots with PCIe Gen4 x4 interface
- 8 x LP PCIe Gen4 x16 slots
- 4 x OCP 3.0 Gen4 x16 and x8 slots
- Dual 2200W (240V) 80 PLUS Platinum redundant power supply
